Key Performance Specifications

• Engine: Cat 3024C or C2.2 naturally aspirated diesel engine
• Net Power: 49 hp (37 kW) at the flywheel
• Gross Power: 51 hp (39 kW)
• Rated Operating Capacity (ROC): 1,400 lbs (635 kg)
• ROC with Optional Counterweights: 1,500 lbs (680 kg)
• Tipping Load: 2,800 lbs (1,270 kg)
• Breakout Force (Tilt Cylinder): 3,787 lbs (1,718 kg) [1, 2, 3, 4]

Machine Weights & Dimensions

• Operating Weight: 5,709 lbs (2,589 kg)
• Overall Length (with bucket): 127 inches (3,225 mm)
• Overall Width (over tires): 60 inches (1,525 mm)
• Height (to top of cab): 76.4 inches (1,940 mm) [1, 2, 3]

Hydraulic System

• Pump Flow: 15.6 gpm (59 L/min)
• System Pressure: 3,335 psi [1]

Notable Features

• Radial Lift Design: Delivers excellent digging performance and superior mid-lift reach.
• Ergonomics: Features pilot-operated joystick controls for low-effort operation and standard 12V power sockets.
• Serviceability: The rear door opens 90 degrees and the entire cab tilts backward for unrestricted access to hydraulic pumps, valves, and engine checkpoints
