Item Details
ID: 17383445
Make: Yamaha
Type: New
Year: 2021
Model: Kodiak
Width: 1180 mm (46.5
Engine: Liquid-cooled, SOHC 4-stroke
Height: 1240 mm (48.8
Length: 2070 mm (81.5
Warranty: One year (unlimited mileage)
Wheelbase: 1250 mm (49.2
Wet Weight: 299 kg (659 lb)
Final Drive: Lever-operated 2WD/4WD; shaft
Lubrication: Wet sump
Seat Height: 860 mm (33.9
Tires (rear): Maxxis MU20, AT25 x 10-12
Transmission: Ultramatic V-belt with all-wheel engine braking; H, L, N, R, P
Brakes (rear): Multi-Disc wet brake
Fuel Capacity: 21.8 L (4.8 Imp. Gal)
Fuel Delivery: Yamaha Fuel Injection (YFI), 44 mm
Tires (front): Maxxis MU19, AT25 x 8-12
Brakes (front): Dual hydraulic disc
Bore And Stroke: 102 mm x 84 mm
Compression Ratio: 10 : 1
Suspension (rear): Adjustable independent double wishbone with anti-sway bar / 232 mm (9.1") of wheel travel
Suspension (front): Independent double wishbone / 180 mm (7.1") of wheel travel
Ignition / Starting: TCI / Electric
Maximum Ground Clearance: 274 mm (10.8")
Item Description
| Offering Proven Off?Road capability and comfort during all-day rides, whether they're filled with chores or trail adventures. The Kodiak 700 is your affordable 700-class ATV. |
|
HIGHLIGHTS
|
 TERRAINABILITY
- Work-Ready Chassis
- The Kodiak 700 tackles rough terrain with ease thanks to plenty of ground clearance and adjustable suspension
- Wide-arc A-arms and full-body skid plates ensure the Kodiak 700 is able to handle anything the farm or trail can throw at it
|
 POWER
- 700-Class engine
- Big-bore engine built to tackle real world chores
- Features Yamaha's class-leading Ultramatic transmission with immediate response and advanced all-wheel engine braking
|
 DESIGN
- Compact ergonomics
- Plush seat improves rider comfort for extended days working and exploring with plenty of room for the rider to move during aggressive riding
- With full-size performance, the Kodiak features a more compact body design similar to a mid-sized ATV to ease overall feel and handling
|
|
Features & BENEFITS
|
Key Features
- Big Bore Engine Built to Tackle the Real World
- High-Performance Ultramatic® Transmission
- Convenient, handlebar mounted 2wd - 4wd drive selector lever.
- Stainless Steel Exhaust
- Drive System Air Intake
- High-Capacity Radiator
|
ENGINE
Big Bore Engine Built to Tackle the Real World
- The Kodiak 700 combines big bore power without losing an ounce of comfort
The 700-class engine with improved midrange performance and optimized torque right where you use it most
- Gearing designed for low rpm cruising and smooth running motor mounts to create excitement on the trails while still being quiet and potent for the job site
High-Performance Ultramatic® Transmission
- Features gated shifter, dual-range (Hi/Lo) drive plus reverse gear
Most advanced and durable CVT system available
- Automatic centrifugal clutch maintains constant belt tension for reduced belt wear
- Sprag clutch delivers natural all-wheel engine braking for control and confidence
- Convenient, handlebar mounted 2wd - 4wd drive selector lever.
- drive system features 2 modes: 2wd & 4wd limited slip
Stainless Steel Exhaust
- Maintains clean-running performance
- Features screen-type spark arrestor for great power with minimum noise output
Drive System Air Intake
- Specially designed, high-mounted drive system air intake
- Helps reduce drive system temperatures and assists in keeping water and debris from entering the drive case
- Increases power and torque while providing additional room for on-board storage
High-Capacity Radiator
- Efficient high-capacity radiator with fan assist that delivers plenty of air flow for maximum cooling efficiency
- Positioned high in the frame for optimal protection
|
Chassis
Trail-Ready Chassis
- With plenty of ground clearance and adjustable suspension, the Kodiak tackles rough terrain with ease.
- Wide-arc A-arms and full-body skid plates ensure the Kodiak is able to handle anything the farm or trail can throw at it
High-Performance Tires
- To maximize available traction, the Kodiak features 25-inch Maxxis® tires
- Provide precise steering feel and feedback
Independent Double Wishbone Front and Rear Suspension
- 7.6 inches of front wheel travel / 9.1 inches of rear wheel travel
- Provides excellent rider comfort even on the toughest trails
- Nitrogen-charged shocks with 5-way adjustable preload
Aggressive and Durable Styling
- Rugged composite front bumper resists scratching and rust
- Injection-molded fenders and CV joint guards protect again rock and debris
Compact Ergonomics
- A plush seat improves rider comfort for extended days exploring
- Plenty of room for the rider to move during aggressive riding
- Despite full size performance, Kodiak features a more compact body design similar to mid-sized ATV for overall ease in handling
Extensive Cargo Capacity
- Rugged, large-diameter steel cargo racks with durable wrinkle paint finish
- 308 pounds of total carrying capacity
- On-board storage compartment keeps things try
Work-Ready Tow Capacity
- Tow up to 600 kg (1322 lb)
Generous Ground Clearance
- Offers impressive 11.3 inches of maximum ground clearance
- Full-length composite skid plate for underbelly protection
|
Design
Ready for Accessories
- Engineered in concert with a range of accessories for perfect fit and function
- Standard 12V power point to keep devices charged.
|
